ホーム > 製品情報 > M.2 (NGFF)系製品 > Samsung SM951 Series

  SM951 Series
(M.2 PCIe Gen3 SSD)


  SAMSUNG M.2 (NGFF) PCIe Gen3 SSD

   SM951 Series (NVMe)

SM951-NVMe-512G
Unit price: USD 470

PART NUMBER SM951-NVMe-512G
(MZVPV512HDGL)
Capacity1) 512GB
LBA2) 1,000,215,216

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 11 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.

Hotfix for windows 8.1
https://support.microsoft.com/zh-cn/kb/2897143

Hotfix for windows 7, server2008 R2
https://support.microsoft.com/en-us/kb/2990941


SM951-NVMe-256G
Unit price: USD 255

PART NUMBER SM951-NVMe-256G
(MZVPV256HDGL)
Capacity1) 256GB
LBA2) 500,118,192

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 11 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.

Hotfix for windows 8.1
https://support.microsoft.com/zh-cn/kb/2897143

Hotfix for windows 7, server2008 R2
https://support.microsoft.com/en-us/kb/2990941


SM951-NVMe-128G
Unit price: USD 140

PART NUMBER SM951-NVMe-128G
(MZVPV128HDGM)
Capacity1) 128GB
LBA2) 250,069,680

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 11 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.

Hotfix for windows 8.1
https://support.microsoft.com/zh-cn/kb/2897143

Hotfix for windows 7, server2008 R2
https://support.microsoft.com/en-us/kb/2990941




   SM951 Series (AHCI)

SM951-AHCI-128G
Unit price: USD 140

PART NUMBER SM951-AHCI-128G
(MZHPV128HDGM)
Capacity1) 128GB
LBA2) 250,069,680

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 11 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.
SM951-AHCI-256G
Unit price: USD 240

PART NUMBER SM951-AHCI-256G
(MZHPV256HDGL)
Capacity1) 256GB
LBA2) 500,118,192

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 11 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.
SM951-AHCI-512G
Unit price: USD 440

PART NUMBER SM951-AHCI-512G
(MZHPV512HDGL)
Capacity1) 512GB
LBA2) 1,000,215,216

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 11 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.





   SM951 Series (NVMe)

FEATURES Environmental Specifications
  • PCIe Gen3 8Gb/s Interface, up to 4 Lanes
  • Compliant with PCI Express Base Specification Rev. 3.0
  • Compliant with NVMe Express specification. Rev.1.1a
  • Power Saving Modes:
    -Supporting APST
    -Supporting L1.2 Mode
  • Support Admin & NVM Command Set
  • End-to-End Data Protection
  • RoHS Compliant
  • Support up to 1 Namespaces
  • Support up to 8 I/O Queues
  • Support up to 16K Queue entries for each I/O Queue
    Temperature (Tc4)
  • Operating 0°C to 70°C
  • Non-operating -40°C to 85°C
    Humidity (non-condensing)
  • Non-operating 5 ~ 95 %
    Linear Shock (1/2 sine pulse, 0.5ms)
  • Non-operating 1,500 G
    Vibration (sine swept, 10~2000Hz, 15min/axis, 3axis)
  • Non-operating 10 ~ 2000 Hz : 20G
Drive Configuration Electrical Specifications
  • From Factor: M.2
  • Interface: PCIe Gen3 8Gb/s x4
  • Bytes per Sector: 512 Bytes
  • Supply Voltage: +3.3V ± 5%
  • Voltage Ripple/Noise (max.): 100mV p-p
  • Active (typical): 6.5W
  • Idle (typical): 50mW
  • L1.2 (Typ): 2mW
Performance Specifications Physical Dimension
    Data Transfer Rate(128KB)
  • Sequential Read: (128GB) Up to 2000 MB/s
  • Sequential Read: (256GB) Up to 2150 MB/s
  • Sequential Read: (512GB) Up to 2150 MB/s
  • Sequential Write: (128GB) Up to 650 MB/s
  • Sequential Write: (256GB) Up to 1260 MB/s
  • Sequential Write: (512GB) Up to 1550 MB/s
    Data I/O Speed(4KB)
  • Random Read : (128GB/256GB/512GB) Up to 100K IOPS
  • Random Write :
    (256GB/512GB) Up to 100K IOPS
    (128GB) Up to 83K IOPS
  • Width: 22.00 ± 0.15 mm
  • Length: 80.00 ± 0.15 mm
  • Height:
    (Double Side) Max 3.73 mm
    (Sigle Side) Max. 2.38 mm
  • Weight
    Up to 10 g
Reliability Specifications Specifications are subject to change without notice.
  • UBER: < 1 sector per 1015 bits read
  • MTBF: 1.5 Million Hours

1)1MB = 1,000,000 Bytes, 1GB = 1,000,000,000 Bytes, Unformatted Capacity.
User accessible capacity may vary depending on operating environment and
formatting.

2) 1 Sector = 512Bytes, Max. LBA represents the total user addressable sectors in LBA mode and calculated by IDEMA rule

3) Actual performance may vary depending on use conditions and environment.

4) Tc is measured at the surface of NAND Flash package.




   SM951 Series (AHCI)

FEATURES Environmental Specifications
  • PCIe Gen3 8Gb/s Interface, up to 4 Lanes
  • Compliant with PCI Express Base Specification Rev. 3.0
  • Support Standard AHCI driver
  • Power Saving Modes:
    -Supporting APM
    -Supporting L1.2 Mode
  • Support NCQ (Up to 32 depth) Command Set
  • Support SSD Enhanced S.M.A.R.T. Feature Set
  • Support TRIM Command
  • End-to-End Data Protection
  • RoHS Compliant
    Temperature
  • Operating 0°C to 70°C
  • Non-operating -40°C to 85°C
    Humidity (non-condensing)
  • Non-operating 5 ~ 95 %
    Linear Shock (1/2 sine pulse, 0.5ms)
  • Non-operating 1,500 G
    Vibration (sine swept, 10~2000Hz, 15min/axis, 3axis)
  • Non-operating 20G
Drive Configuration Electrical Specifications
  • From Factor: M.2
  • Interface: PCIe Gen3 8Gb/s x4
  • Bytes per Sector: 512 Bytes
  • Supply Voltage: +3.3V ± 5%
  • Voltage Ripple/Noise (max.): 100mV p-p
  • Active (typical): 6.5W
  • Idle (typical): 50mW
  • L1.2 (Typ): 2mW
Performance Specifications Physical Dimension
    Data Transfer Rate(128KB)
  • Sequential Read: (128GB) Up to 2000 MB/s
  • Sequential Read: (256GB) Up to 2150 MB/s
  • Sequential Read: (512GB) Up to 2150 MB/s
  • Sequential Write: (128GB) Up to 600 MB/s
  • Sequential Write: (256GB) Up to 1200 MB/s
  • Sequential Write: (512GB) Up to 1500 MB/s
    Data I/O Speed(4KB)
  • Random Read : (128GB/256GB/512GB) Up to 90K IOPS
  • Random Write : (128GB/256GB/512GB) Up to 70K IOPS
  • Width: 22.00 ± 0.15 mm
  • Length: 80.00 ± 0.15 mm
  • Height:
    (Double Side) Max 3.73 mm
    (Sigle Side) Max. 2.38 mm
  • Weight
    Up to 10 g
Reliability Specifications Specifications are subject to change without notice.
  • UBER: < 1 sector per 1015 bits read
  • MTBF: 1.5 Million Hours

1) 1MB = 1,000,000 Bytes, 1GB = 1,000,000,000 Bytes, Unformatted Capacity.
User accessible capacity may vary depending on operating environment and
formatting.

2) 1 Sector = 512Bytes, Max. LBA represents the total user addressable sectors in LBA mode and calculated by IDEMA rule
